EPIREZ® General Purpose Epoxy Mortar Binder 133
EPIREZ® General Purpose Epoxy Mortar Binder is a solventless epoxy binder designed for multi-purpose epoxy mortar and concrete applications where high structural integrity is required. Its low mixed viscosity, wet-surface bonding capability and fast hardening help produce high-strength epoxy mortars and concretes.
When combined with EPIREZ aggregates, the binder can be used to prepare epoxy mortars and concretes for structural repairs, concrete lining, grouting and steel-to-concrete bonding.
The cured system provides excellent adhesion, high compressive and tensile strength, and resistance to the entry and passage of water and corrosive ions. It also provides high chemical resistance and a non-shrink formulation.
EPIREZ® General Purpose Epoxy Mortar Binder has been independently tested and complies with AS/NZS 4020:2018 for use with potable water.
The product was previously named EPIREZ® 133.
Key Features and Benefits
- Multi-purpose epoxy binder: Designed for mortar and concrete repair applications.
- Solventless formulation: Contains 100% solids and 0 g/L VOC.
- Wet-surface bonding: Provides excellent adhesion to wet or dry concrete.
- Low mixed viscosity: 12,000–18,000 cP according to the technical data.
- High mechanical strength: Ultimate compressive strength is 95 MPa.
- High tensile strength: Ultimate tensile strength is 55 MPa.
- High chemical resistance: Provides resistance in demanding repair environments.
- Non-shrink: Designed for epoxy mortar and concrete applications requiring dimensional stability.
- Aggregate extendable: Can be combined with EPIREZ® aggregates to prepare epoxy mortars and concretes.
- Low-temperature cure: Suitable for application temperatures from 10°C to 30°C.
Where Can EPIREZ® General Purpose Epoxy Mortar Binder Be Used?
EPIREZ® General Purpose Epoxy Mortar Binder is designed for a range of structural bonding, repair and grouting applications.
- Structural bonding of new to old concrete lining
- Structural repair of spalled concrete and masonry
- Grouting load-bearing bolts and supports into concrete
- Splash-zone repairs to concrete and timber structures
- Bonding steel to concrete
Preparing Epoxy Mortar and Concrete
EPIREZ® General Purpose Epoxy Mortar Binder can be combined with EPIREZ® aggregates to prepare high-strength epoxy mortars and concretes.
The estimating data provides an example of a 4 L binder combined with 16 L of EPIREZ® Patching & Flooring Mortar Aggregate (QA2) to produce approximately 4 m² at 4 mm thick.
Coverage and Estimating Data
| Binder / System | Estimated Coverage | Thickness |
|---|---|---|
| 1 L EPIREZ® General Purpose Epoxy Mortar Binder | 1 m² | 1 mm DFT |
| 4 L Binder + 16 L EPIREZ® Patching & Flooring Mortar Aggregate (QA2) | 4 m² | 4 mm thick |
Application Temperature
EPIREZ® General Purpose Epoxy Mortar Binder has a stated application temperature range of 10°C to 30°C.
The product provides a low-temperature cure within its specified application temperature range.
Mixing Ratio
The mixing ratio is 1 part Hardener to 3 parts Compound.
The pot life at 25°C is approximately 30 minutes, so mixed material should be used within the available working time.
Drying and Cure Times
- Pot life at 25°C: 30 minutes
- Tack-free time at 25°C: 6 hours
- Hardening time at 25°C: 24 hours
- Full chemical resistance: 7 days at 25°C
Mechanical Strength
After curing for 7 days, the technical data provides the following mechanical properties:
- Ultimate compressive strength: 95 MPa
- Compressive modulus: 3.4 GPa
- Ultimate tensile strength: 55 MPa
These values are representative or typical technical data and should not be used for specification purposes.
Water and Chemical Resistance
EPIREZ® General Purpose Epoxy Mortar Binder provides resistance to the entry and passage of water and corrosive ions.
- Water permeability: 2.0 × 10-17 m·s-1
- Resistance to corrosive ions: Designed to resist their entry and passage.
- Full chemical resistance: 7 days at 25°C.
Potable Water Use
EPIREZ® General Purpose Epoxy Mortar Binder has been independently tested and complies with AS/NZS 4020:2018 for use with potable water.
Temperature Resistance
- Wet: 65°C
- Dry: 120°C
Technical Specifications
| Specification | Technical Data |
|---|---|
| Product | EPIREZ® General Purpose Epoxy Mortar Binder |
| Previous Name | EPIREZ® 133 |
| Product Type | Solventless epoxy mortar and concrete binder |
| Solids Content | 100% |
| VOC Content | 0 g/L |
| Mixing Ratio | 1 Hardener : 3 Compound |
| Pot Life @ 25°C | 30 minutes |
| Tack Free Time @ 25°C | 6 hours |
| Hardening Time @ 25°C | 24 hours |
| Full Chemical Resistance | 7 days at 25°C |
| Mixed Viscosity | 12,000–18,000 cP |
| Application Temperature | 10°C to 30°C |
| Ultimate Compressive Strength | 95 MPa |
| Compressive Modulus | 3.4 GPa |
| Ultimate Tensile Strength | 55 MPa |
| Water Permeability | 2.0 × 10-17 m·s-1 |
| Temperature Resistance — Wet | 65°C |
| Temperature Resistance — Dry | 120°C |
| Potable Water | Complies with AS/NZS 4020:2018 for use with potable water |
| Concrete Coverage | 1 m² per litre at 1 mm DFT |
| Binder + Aggregate Coverage | 4 m² using 4 L Binder + 16 L QA2 Aggregate at 4 mm thick |
Important: The information on this page is a summary of the supplied technical information. Always read the current manufacturer's Technical Data Sheet before mixing, surface preparation or application.
